| Panel
Dimensions |
|
Minimum
size
|
8¡¨¡Ñ12¡¨ |
| 203¡Ñ305mm |
|
Maximum
size
|
DP-1500-2X |
24¡¨¡Ñ30¡¨
|
610¡Ñ762mm |
| DP-1500-2XL |
24¡¨¡Ñ36¡¨
|
610¡Ñ914mm |
| Minimum
thickness |
0.010¡¨0.25mm |
| Maximum
thickness¡¯ |
0.250¡¨6.4mm |
| ¡¯Optional
fixtures available to accommodate panels up to 0.400¡¨ |
| Productivity |
| Panel
size |
12¡¨
305mm |
18¡¨
454mm |
24¡¨
610mm |
30¡¨
762mm |
36¡¨
914mm |
Flood/Print
|
20
sec |
22
sec
|
24
sec |
26
sec
|
28
sec |
| Flood/Print/print |
25
sec |
27
sec |
29
sec |
31
sec |
33
sec |
|
Cycle
time is to load, coat, and unload a panel with LPI soldermask. ¡§Panel
size¡¨ is the dimension in the direction of coating. Different inks
can require different print and flood speeds for optimal results.
¡¯(DP-1500-2XL only)
|
| Coating
Features |
| Coating
Modes |
Flood
and print |
|
Flood,
print, print |
|
Flood,
print. Flood, print, print |
|
Flood
only |
|
Fully
manual |
|
No
Flood Printing |
|
Reverse
home position flooding |
| Print
speed |
1.0
to 10 in/sec 2.5-25 cm/sec |
| Flood
Speed |
1.0
to 10 in/sec 2.5-25 cm/sec |
| Skew |
Squeegee
may be skewed or straight skew is reversible on alternate strokes |
| Servo
Positioning |
Provides
for precise panel positioning |
| Allows
jogging of a panel between prints |
| Permits
shuffle of panel between print strokes |
| Shipping |
| Net
Weight |
2500
lbs
|
1136
kilos |
| Gross
Weight |
3000
lbs
|
1364
kilos |
Crated
Dimensions
|
Length |
106¡¨
|
2692
mm |
| Width |
46¡¨
|
1168
mm |
| Height |
92¡¨
|
2337
mm |
| |
